Introducing the EG6 fuel pump dispenser – The heart of this EG6 fuel pump dispenser is its intelligent motherboard, capable of wireless data transmission to the fuel management system. This feature allows for seamless integration with the management system. The system ensures robust data security, enabling real-time monitoring to prevent fraudulent activities and safeguard the interests of the gas station. Additionally, the smart fuel dispenser offers an optional 15-inch LED display, providing an excellent platform for advertising promotion.
Advantages and Features
● License Plate Recognition and Automatic Fuel Allocation: The integrated license plate recognition system automates the fueling process by identifying the vehicle's license plate and location. When a vehicle arrives, the camera identifies its license plate and parking position. Based on the vehicle's fueling preferences, the system automatically assigns the correct nozzle. The attendant follows the instructions on the large screen, selects the appropriate nozzle, and starts refueling. After fueling is complete, the system automatically generates an order and deducts the payment, with the result displayed on the screen. The vehicle then departs. Customers need to register in advance with their license plate as the primary identification. Each diesel pump machine is equipped with its own camera, enabling unattended refueling for drivers who wish to self-serve.
● Advanced Payment Options: The EG6 smart fuel dispenser supports QR code payments and IC card swiping, offering convenient, contactless payment methods for customers. This modern solution enhances the fueling experience by enabling fast, secure transactions with no need for physical cash.
● RFID System for Vehicle Identification: Equipped with an RFID system, fuel pump machine can automatically identify vehicles through car cards or vehicle tags, streamlining the fueling process. By recognizing authorized vehicles, the system ensures accurate fuel dispensing and payment, while reducing the need for manual intervention.
● Flexible Nozzle Configurations: The dispenser offers multiple nozzle configurations to meet a wide variety of fuel types and customer needs. From 2 hoses, 4 hoses, 6 hoses to 8 hoses, whether for gasoline, diesel, or other fuels, this versatility ensures compatibility with different types of vehicles, making it suitable for a broad range of fueling requirements.
● 15-Inch LED Display for Promotions and Advertising: The large 15-inch LED screen not only enhances the user experience but also provides a platform for displaying promotional content or advertisements, helping businesses generate additional revenue.
Mechanical parts
Electronic parts
Basic configuration
Basic models and standard features:
Standard duty : 50 liter per min. Optional 70 liter per min.
Vane pump and 4-piston flow meter,optional gear type pump
380Vor 220V explosion proof motor
Suction or submersible type
Rs485 and current loop for POS communication
Emergency button stop
Optional features
15 inch LED optional for advertisement
Built in printer for receipt
Customized logo painting on front panel
Card reader for prepay petro card
Model type
|
Model |
Pump |
Nozzle Oil Products |
Dimension(mm) |
|
EG6-222G-L23 G or S |
G: Gear pump S: submersible type |
2 hose,2 product,2 displays |
Net size:1650*620*2380 Package:1806*1000*2500 |
|
EG6-424G-L23 G or S |
4 hose,2 product,4 displays |
Net size:1650*620*2380 Package:1806*1000*2500 |
|
|
EG6-422G-L23 G or S |
4 hose,2 product,2 displays |
||
|
EG6-634G-L23 G or S |
6 hose,3 product,4 displays |
Net size:1870*620*2380 Package:2020*1000*2500 |
|
|
EG6-632G-L23 G or S |
6 hose,3 product,2 displays |
Certification
Eaglestar ensures high-quality dispenser gas station through rigorous certification processes, including explosion-proof, measuring instrument, and ISO quality certifications, reflecting our professional manufacturing qualifications.
Factory showing
Package and Delivery
We utilize durable, insect-resistant wooden packaging and foam rubber cushions to ensure our dispenser gas station arrives undamaged by sea.
Customer cases
Our petrol station pump have achieved global reach, leading to lasting partnerships with several international industry leaders.
Customer visiting
Sincerely welcome our customers to visit our factory in China
FAQ
Q: Does the display screen of the petrol pump machine support multiple languages?
Q: What materials are used in the construction of the Eaglestar dispenser?
Q: How often does the maintenance cycle of the diesel dispenser need to be carried out?
Q: Can the appearance design of the fuel dispenser be customized?
Q: Why Should You Buy from Us Instead of Other Suppliers?
